Drone Gimbal Camera
Created with Pixso.

Infrared Drone Gimbal Camera LRF High Resolution With GPS Coordinate Resolving

Infrared Drone Gimbal Camera LRF High Resolution With GPS Coordinate Resolving

Brand Name: GS
Model Number: A30TR
MOQ: 1
Price: 1$,Negotiable
Payment Terms: T/T
Supply Ability: 100
Detail Information
Imager Sensor:
1/2.8" SONY CMOS
Lens:
30x Optical Zoom,f=4.3~129mm
Total Pixel:
2.13MP
AI Function:
Human/Vehicle Identification And Tracking
Object Tracking:
Working Voltage:
4S~6S
Output:
1080P Micro HDMI / IP
Control Method:
UDP / PWM / PPM / UART / S.BUS / TCP
Local Storage:
SD Card Up To 128G
N.W.:
1084g
Dimension:
130*134.7*201.4mm
Thermal Imager:
640*512, 19mm Lens, 12μm
Laser Range:
Laser Range 5~1500m
Packaging Details:
130*134.7*201.4mm
Highlight:

Infrared Drone Gimbal Camera

,

Infrared gimbal thermal camera

,

High Resolution gimbal thermal camera

Product Description
30x EO+IR AI Object Tracking Gimbal Camera LRF With GPS Coordinate Resolving
Technical Specifications
Attribute Value
Imager sensor 1/2.8" SONY CMOS
Lens 30x optical zoom, f=4.3~129mm
Total pixel 2.13MP
AI Function Human/Vehicle identification and tracking
Object Tracking
Working voltage 4S~6S
Output 1080P micro HDMI / IP
Control method UDP / PWM / PPM / UART / S.BUS / TCP
Local storage SD card up to 128G
N.W. 1084g
Dimension 130*134.7*201.4mm
Thermal imager 640*512, 19mm lens, 12μm
Laser range 5~1500m
Advanced Imaging System

The 30x EO+IR AI Object Tracking Gimbal Camera combines electro-optical and infrared imaging with AI capabilities, GPS coordinate resolving, and laser rangefinder for precise object tracking and geolocation.

Dual Sensor Capability
  • Electro-Optical Sensor: High-resolution 1/2.8" SONY CMOS sensor for detailed visual imaging in daylight conditions
  • Infrared Sensor: 640*512 thermal imager with 19mm lens for effective operation in low-light/no-light conditions
GPS Coordinate Resolving
  • Determines and provides GPS coordinates of tracked objects
  • Transmits real-time data to ground control stations for immediate analysis
Advanced Imaging Features
  • 30x optical zoom lens with image stabilization
  • AI-powered human/vehicle identification and tracking
  • Integrated laser rangefinder (5-1500m)
  • 1080P output via micro HDMI or IP
Infrared Drone Gimbal Camera LRF High Resolution With GPS Coordinate Resolving 0
Warranty & Support
  • 1 Year Warranty included
  • 14-day return policy for unsatisfied customers
  • Free replacement for defective items within 3 months
  • Continued support after warranty period (shipping fees apply)
Infrared Drone Gimbal Camera LRF High Resolution With GPS Coordinate Resolving 1
Infrared Drone Gimbal Camera LRF High Resolution With GPS Coordinate Resolving 2
Frequently Asked Questions
Q: Do you support OEM/ODM?
A: Yes, we can print your logo on the product.
Q: What is the sample lead time?
A: Samples ready in 7 days (10-20 days for OEM/ODM). Sample fee and shipping apply.
Q: What is the production lead time?
A: 15 days for regular orders, 25-45 days for OEM/ODM depending on quantity.
Q: Is there a minimum order quantity?
A: No MOQ - wholesale orders from 1 piece accepted, including OEM/ODM.
Q: What are your payment terms?
A: We accept L/C and TT (100% payment).
